260W beam moving (SR-260)
specification
instructions downloads
light data bank

SR-260  (5prism and 2prism can be choosed)

BULB:  9R
POWER CONSUMPTION: 230 V 50 HZ 400 VA
OPTICAL DEVICE: high efficiency lens group,0°-1.5°zoom
ELECTRONIC FOCUS: 20 meters, 130000 LUX
CHANNEL MODE: 16 standard DMX512 channel
LEVEL SCANNING: 540 (16 bit precision scan)
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 13color and white light
            with two-way rotating and rainbow effect
ROTATING GOBO WHEEL: 13 gobos and white circle
    with design jitter and arbitrary positioning function
PRISM: 5 prism,2 prism wheel with superposition,
    positive and negative rotation .
SHUT: Double pole shut up to 13 times per second,
   random shut and pulse shut can be choosed
DIMMER: 0%-100% linear dimmer
FROST: 0%-100% linear frost
Electronic ballast : make the product more light and bright.
Lamp more stable environmental protection and more energy saving
SWITCHING POWER SUPPLY : AC100-240 V, 50/60 HZ
FIXTURE DIMENSION: L310×250×520(mm)
PACKING DIMENSION: L405×320×615(mm)
NET WEIGHT: 14KG
GROSS WEIGHT: 16KG
