- The page is：Products > SRT-230mini 230w beam
specification
instructions downloads
light data bank
VOLTAGE:AC100 - 240V 50/60Hz
LIGHT SOURCE: 7R,230W
POWER CONSUMPTION: 280W
OPTICAL DEVICE: high efficiency lens group,0°-2°zoom
ELECTRONIC FOCUS: 20 meters, 45000 LUX
CHANNEL MODE: 16 standard DMX512 channel
LEVEL SCANNING: 540 (16 bit precision scan)
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 13color and white light
with two-way rotating and rainbow effect
GOBO WHEEL: 14 gobos and white circle
with design jitter and arbitrary positioning function
PRISM: 1prism,1 prism wheel with superposition,
positive and negative rotation.
SHUT: shut up to 10 times per second,
random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
EFFECT: 6 color wheel
Electronic ballast : make the product more light and bright.
Lamp more stable environmental protection and
more energy saving
SWITCHING POWER SUPPLY :AC1G0 ~ 240 V, 50/60 HZ
FIXTURE DIMENSION: L284×W234×H441(mm)
PACKING DIMENSION: L500×W345×H365(mm)
NET WEIGHT: 9.8KG
GROSS WEIGHT: 11.5KG
LIGHT SOURCE: 7R,230W
POWER CONSUMPTION: 280W
OPTICAL DEVICE: high efficiency lens group,0°-2°zoom
ELECTRONIC FOCUS: 20 meters, 45000 LUX
CHANNEL MODE: 16 standard DMX512 channel
LEVEL SCANNING: 540 (16 bit precision scan)
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 13color and white light
with two-way rotating and rainbow effect
GOBO WHEEL: 14 gobos and white circle
with design jitter and arbitrary positioning function
PRISM: 1prism,1 prism wheel with superposition,
positive and negative rotation.
SHUT: shut up to 10 times per second,
random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
EFFECT: 6 color wheel
Electronic ballast : make the product more light and bright.
Lamp more stable environmental protection and
more energy saving
SWITCHING POWER SUPPLY :AC1G0 ~ 240 V, 50/60 HZ
FIXTURE DIMENSION: L284×W234×H441(mm)
PACKING DIMENSION: L500×W345×H365(mm)
NET WEIGHT: 9.8KG
GROSS WEIGHT: 11.5KG
