TECHNICAL PARAMETER:
VOLTAGE: AC100- 240V 50/60Hz
LIGHT SOURCE: 250W x2
POWER CONSUMPTION: 600W
OPTICAL DEVICE: high efficiency lens group,0°-2°zoom
ELECTRONIC FOCUS: 20 meters, 45000 LUX
CHANNEL MODE: 23 standard DMX512 channel
LEVEL SCANNING: Infinite angle rotation
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 12color and white light
with two-way rotating and rainbow effect
GOBO WHEEL: 11 gobos and white circle
with design jitter and arbitrary positioning function
PRISM: 1prism, prism wheel with superposition,
positive and negative rotation.
SHUT: shut up to 10 times per second,
random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
Electronic ballast : make the product more light and bright.
Lamp more stable environmental protection and
more energy saving
SWITCHING POWER SUPPLY : AC1G0 ~ 240 V, 50/60 HZ
FIXTURE DIMENSION: L702×W270×H445(mm)
PACKING DIMENSION: L800×W330×H500(mm)
NET WEIGHT: 18.8KG
GROSS WEIGHT: 22.5KG
VOLTAGE: AC100- 240V 50/60Hz
LIGHT SOURCE: 250W x2
POWER CONSUMPTION: 600W
OPTICAL DEVICE: high efficiency lens group,0°-2°zoom
ELECTRONIC FOCUS: 20 meters, 45000 LUX
CHANNEL MODE: 23 standard DMX512 channel
LEVEL SCANNING: Infinite angle rotation
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 12color and white light
with two-way rotating and rainbow effect
GOBO WHEEL: 11 gobos and white circle
with design jitter and arbitrary positioning function
PRISM: 1prism, prism wheel with superposition,
positive and negative rotation.
SHUT: shut up to 10 times per second,
random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
Electronic ballast : make the product more light and bright.
Lamp more stable environmental protection and
more energy saving
SWITCHING POWER SUPPLY : AC1G0 ~ 240 V, 50/60 HZ
FIXTURE DIMENSION: L702×W270×H445(mm)
PACKING DIMENSION: L800×W330×H500(mm)
NET WEIGHT: 18.8KG
GROSS WEIGHT: 22.5KG
