- The page is:Products > 37x15W, 4 in 1 LED moving head light(YLD-3715)
Model:YLD-3715
Rated voltage: AC100V ~ 240V 50/60Hz
Input power: 600W
Light source specifications: 37 15W four in one LED Osram light source
Approved life: 50,000 hours
Color: red, green, blue and white multi-color
Focusing: 4 ° -60 ° DMX linear focus, with automatic focus function
Color temperature control: built-in CTO DMX linear dimming
Electronic strobe, 0.3 ~ 25 times / second, can choose synchronous, asynchronous random strobe
Dimming: electronic dimming 0 ~ 100% linear adjustment, with a gamma curve dimming frequency 1.2K ~ 25K adjustable, with macro command dimming linear stable and smooth without flicker, using a stable constant current driver and power supply, suitable for video shooting
Rotation angle: XY axis using high-speed silent 60 three-phase motor drive, with high-precision imported Hall positioning device, so that the operation of more accurate positioning, when the misstep can automatically return to the horizontal, vertical speed adjustable; XY axis rotation function and take the reverse function
Horizontal direction 540 ° (16 bit precision scanning), vertical direction 270 ° (16 bit precision scanning)
Control mode: 22 (streamlined) / 50 (standard) 2 channel control mode, standard DMX512 protocol, RDM protocol
Control interface: DMX512 interface (3-core / optional 5-core), power cord hand-held socket
Hibernation function: the use of advanced technology to achieve remote hibernation function, when the lamps and lanterns disconnect the signal automatically into the hibernation state, so that the lamps and lanterns more stable and safer
Display function: 1.77 inch LCD display, bilingual menu, sensor fault display, temperature display
Heat dissipation system: using high conductivity light aluminum heat sink, fan intelligent monitoring technology according to the temperature of the lamps and lanterns automatically adjust the fan rotation, built-in overheating protection intelligent system / intelligent temperature and noise balance module
Protection grade: IP20, optional rain cover protection grade up to IP44
Net weight: 13.50KG
Gross weight: 15.55KG
Product size: 35*29*41CM
Package size: 47*34*52CM
