Model number:B-400BSW

380W beam 3 in 1 Gobo beam light

voltage: 100-240V, 50/60Hz

Bulb model: Original Osram 371W

Bulb power: 550W

Color wheel: A color wheel , 13 color + 1 white light

Gobo wheel: Two gobo wheels, fix gobo wheel with 14 gobos and white light, rotating gobos with 9 gobos, can customize customer logos, and gobos can be linearly and infinitely enlarged or reduced

Rotating gobos diameter: 15.8 mm

Effective inner diameter: 12mm

Effect wheel: can rotate a circular octaprism, with 0-100% mechanical dimming, supporting mechanical strobe and adjustable strobe effects, and supporting strobe macro function.

Lens group optical system, electric focusing, beam angle 2.8-38 °.

Adopting a photoelectric reset system, it can automatically retrieve and reset in case of accidental misoperation.

Channel mode: 17 channel mode.

The rotation angle is 540 ° pan, with a resolution of 8Bit/16Bit, and 270 ° tilt, with a resolution of 8Bit/16Bit.

Overheat protection.

Waterproof grade: IP56

Electronic rectifier.

Net weight: 27Kg,

Gross weight: 33.28KG

Fixture dimensions: 424 * 367 * 725mm

Packing dimensions: 601 * 530 * 735mm

2 in 1 flightcase: 92 * 47 * 90cm   Weight: 93kg

Appearance: The light is made of high-strength engineering nylon plastic, anti UV treatment, high temperature resistant, anti-aging+high temperature resistant die-casting aluminum shell, lightweight, and adopts wind direction drainage and temperature intelligent monitoring technology, so it can dissipate heat quickly!

Features: No signs of weakness, compact appearance, huge energy, and thick light column.
