Voltage: AC110V-240V/50-60HZ

Light source : 400W white LED module

Color temperature: 8000k Color rendering index: 75

Light source lifespan: 50000 hours

Illumination: 4 meters 80000 LUX

Power: 500W

Channel mode: 22 and 26 channels

Dimming : 0-100% linear adjustment

Focus: linear adjustment from 4 meters to 50 meters

Frost: 1 independent frost effect, soft and natural light spot

Zoom angle: 4-35 degrees

High speed strobe: 0-30 times/second, adjustable strobe effect - strobe macro function

Color: 12 colors+white light color half color function

Color system: Independent CMY+CTO color mixing system.

Fix gobo wheel: 12 fix gobos+white light

Rotating gobo wheel: 7 glass gobos, each with independent forward and reverse rotation

Prism system: standard with a single 8-row calibration mirror and 8-prism, each prism can be independently reversed and stacked with functions

Macro function: console reset function, self running mode, master-slave mode

Display mode: LCD display, button+touch dual operation mode

Control signal: International standard DMX512. With RDM function, online software upgrade is possible, and address code can be removed

Cooling method: use axial fan for enhanced cooling

Safety devices; Equipped with electronic temperature control overheat protection, electronic temperature control automatically power-off protection in case of overheat system failure

Pan/Tilt: Waterproof lights can perform 540 ° pan or 270 ° tilt scanning, with fast and stable speed,

Intelligent photoelectric reset and correction system is set up for lighting fixtures, which can automatically recover in case of accidental misoperation

The original position. In addition, it has a horizontal and vertical locking button, making maintenance and handling more convenient.

Heat dissipation system:

Use CFD software to analyze and calculate the heat flow rate of lights, and design a low noise heat dissipation system

The fan drive has excellent performance and extremely low noise.

Waterproof grade: IP65

Net weight: 27KG

Gross weight: 33.28KG

Fixture dimensions: 424×367×725mm

Packing dimensions: 601×530×735mm

2 in one flightcase size: 92×47×90cm Weight: 93kg

Appearance: The fixture is made of high-strength engineering nylon plastic, anti UV treatment, high temperature resistant, anti-aging+high temperature resistant die-casting aluminum shell, lightweight, and adopts wind direction drainage and temperature intelligent monitoring technology, so it can dissipate heat quickly!
