SR-440

BULB:   420W   Osram bulb
POWER CONSUMPTION:  600W
OPTICAL DEVICE: high efficiency lens group,0°-2°zoom
ELECTRONIC FOCUS: 20 meters,  210000 LUX
CHANNEL MODE: 16  standard  DMX512 channel
LEVEL SCANNING: 540 (16 bit precision scan)
VERTICAL SCAN: 280 (16 bit precision scan)
COLOR WHEEL: 14color and white light with two-way rotating and rainbow effect
FIXED GOBO WHEEL: 17 gobos and white circle with design jitter and arbitrary positioning function
PRISM:  two prism,48-facet  circular prism , 16-facet linear prism， with superposition,positive and negative rotation  and prism location function.
SHUT: Double pole shut up to 13 times per second,random shut and pulse shut can be choosed
DIMMER: 0% ~ 100% linear dimmer
FROST: 0% ~ 100% linear frost
Electronic ballast : make the product more light and bright.Lamp more stable environmental protection and more energy saving
SWITCHING POWER SUPPLY : AC100 ~ 240 V,  50/60 HZ
FIXTURE DIMENSION: L400×W320×H650(mm)
PACKING DIMENSION: L470×W450×H680(mm)
NET WEIGHT: 21KG
GROSS WEIGHT: 24KG

Fixture Library for SR-440(d4)

Fixture Library for SR-440(R20)
